| 是否进口：否 | 品牌：SQUARE-D | 型号：9012GAW4 |
| 类型：机械压力开关 | 3C额定电压范围：440V及以下 | 额定电压：220V |
| 额定电流：20A | 机械寿命：5000000万次 | 最大工作压力：120Pa |
| 产品认证：UL | 加工定制：否 |
9012GAW4---
industrial pressure switch, 9012G, adjustable scale, 2 thresholds, 1.5 to 75 psig
----------------------------------------------
9012GAW4
9012GAW4K1
9012GAW5
9012GAW5K1
Range of Product
9012G
pressure sensor type
Electromechanical pressure switch
pressure sensor name
9012G
pressure sensor size
75 psi (517.11 kPa)
maximum pressure
240 psi
contacts type and composition
NC-NO, SPDT-DB, Form Z, snap action, silver nickel contacts
controlled fluid
Hydraulic oil -40鈥�250 掳F (-40鈥�121 掳C))
Non-corrosive liquids
Air
Non-corrosive gas
fluid connection type
0.25 inch 18 NPTF UL 508
pressure switch type of operation
Regulation between 2 thresholds
scale type
Adjustable differential
local display
Without
range on decreasing pressure
1.5鈥�75 psi (10.34鈥�517.11 kPa)
approx adjustable differential at mid range
3.5鈥�15 psi (24.13鈥�103.42 kPa) +/- 2.5 % full scale
cable entry
0.5 inch NPT conduit entrance
terminal block type
4 screw terminals
electrical connection
Screw-clamp terminals, AWG 22...AWG 12
electrical circuit type
Control circuit
local signalling
Without
Line Rated Current
3 A 240 V AC A600 NEMA rating designation
6 A 120 V AC A600 NEMA rating designation
0.27 A 250 V DC R300 NEMA rating designation
0.22 A 125 V DC R300 NEMA rating designation
setting
Internal
Enclosure Material
Die cast aluminium alloy 380
pressure actuator
Diaphragm nitrile (Buna-N)
Height
5.55 in (140.97 mm)
Depth
2.63 in (66.80 mm)
Width
3.5 in (88.90 mm)
operating position
Any position
materials in contact with fluid
Zinc plated steel
Nitrile (Buna-N)
short-circuit protection
10 A cartridge overload and short-circuit protection gL
maximum operating rate
120 cyc/mn
mechanical durability
5000000 cycles
repeat accuracy
4 %
Net Weight
3 lb(US) (1.36 kg)
Environment
vibration resistance
2 gn 40鈥�150 Hz)IEC 68-2-6
shock resistance
50 gn IEC 58-2-27
standards
UL 508
CSA C22.2 No 14
CE
product certifications
UL listed file E12158 CCN NKPZ and CCN NTHT
CSA LR25490 class 3211 03
CE
NEMA degree of protection
NEMA 4/4X/13 UL 50
Ambient Air Temperature for Operation
-10鈥�185 掳F (-23鈥�85 掳C)
